Available Sizes (16 options)
Popular Sizes
| Part # | Color | A (in.) | B (in.) | C (in.) | D (in.) | E (in.) | Qty/Bag | Price/Bag | Add to Shopping List |
|---|---|---|---|---|---|---|---|---|---|
| HTP5-04 | Lt Green | 0.906 | 1.063 | 1.000 | 0.492 | 0.750 | 100 | $45.76 | |
| HTP6-04 | Dk Blue | 1.031 | 1.260 | 1.000 | 0.610 | 0.750 | 100 | $57.53 | |
| HTP7-04 | Dk Blue | 1.188 | 1.438 | 1.000 | 0.688 | 0.750 | 100 | $71.91 | |
| HTP8-04 | Lt Blue | 1.313 | 1.625 | 1.000 | 0.813 | 0.750 | 100 | $99.36 | |
| HTP9-04 | Red | 1.469 | 1.750 | 1.000 | 0.969 | 0.750 | 100 | $124.20 | |
| HTP10-04 | Red | 1.653 | 1.968 | 1.000 | 1.244 | 0.750 | 50 | $84.98 | |
| HTP10.5-04 | Clear | 1.78 | 2.090 | 1.000 | 1.125 | 0.750 | 50 | $78.44 | |
| HTP11-04 | Dk Blue | 1.890 | 2.203 | 1.000 | 1.39 | 0.750 | 50 | $92.82 | |
| HTP11.5-04 | Dk Green | 1.969 | 2.469 | 1.000 | 1.219 | 0.625 | 50 | $101.98 | |
| HTP12-04 | Red | 2.125 | 2.500 | 1.000 | 1.375 | 0.625 | 50 | $108.51 | |
| HTP13-04 | Lt Blue | 2.281 | 2.688 | 1.000 | 1.531 | 0.625 | 50 | $124.20 | |
| HTP13.5-04 | Purple | 2.438 | 2.953 | 1.375 | 1.688 | 1.000 | 50 | $166.04 | |
| HTP13.7-04 | Lt Green | 2.677 | 3.228 | 1.677 | 1.000 | 1.000 | 10 | $70.60 | |
| HTP14-04 | White | 3.000 | 3.500 | 1.500 | 2.000 | 1.000 | 10 | $61.45 | |
| HTP15-04 | Rusty Red | 3.250 | 4.000 | 1.500 | 2.250 | 1.000 | 10 | $94.13 | |
| HTP16-04 | Clear | 3.500 | 5.000 | 2.000 | 3.071 | 1.181 | 5 | $96.75 |
Technical Specifications
Properties
Application Tips
Insertion Depth
Irregular Holes
Threaded Holes
Insertion Depth
Plug insertion depth should be roughly 1/2 to 2/3 of its total length.
Irregular Holes
Hollow core allows the walls to collapse slightly, ideal for irregular holes.
Threaded Holes
Flexible walls bite into threads for superior liquid-tight seals on threaded holes.
Need a Custom Size?
We provide custom slit widths and die-cut shapes to your exact specifications.
- Low-cost tooling, 7-10 day lead time
- Large inventory of in-stock tools
- Rectangles, squares, circles, and custom shapes
- Precision slit-to-width available
- Free samples on most products
